Branch Pipe Layouts: A Handy Tool for Fabrication Engineers
Branch Pipe Layouts is a free Android app designed by LetsFab under the Education & Reference category. It is a useful tool for fabrication engineers, piping engineers, production engineers, quality engineers, costing and estimating engineers, AutoCAD engineers, and design engineers who are engaged in the fabrication of process equipment.
The app is built to provide fabrication layout or flat pattern layout for plain pipes or shells, pipe to pipe intersection at 90 degrees with equal diameter, pipe to pipe intersection at 90 degrees with unequal diameter with offset distance, and pipe or nozzle to cone intersection at 90 degrees or pipe or nozzle to cone intersection with parallel axis. The app also provides flat pattern or fabrication layout options for pipe branch cutting, pipe tee branch, and pipe Y formation.
The app's interface is user-friendly, and it is straightforward to use. Users can input the required dimensions and get the desired flat pattern or fabrication layout. The app also gives the option to enter a manual desired value for lay outing flat pattern of branch pipe. Overall, Branch Pipe Layouts is a helpful tool for engineers who are engaged in the fabrication of process equipment.
